210 Series N-type 700-720W



Advantages:
1. G12 Monocrystalline Cells, Higher Output
2. High Output Power, Using PERC Technology (Low Resistance Characteristics), Output Power Of 132pcs Monocrystalline Cells Reaches Max 720W (Highest Conversion Efficiency To 23.2%)

3. Low Light Performance, Using Excellent Glass And Texture Surface Making Of Solar Cell, Outstanding Performance Can Be Obtained In Low Light Condition.

4. Adaptability Of Harsh Environment, Corrosion Tests Have Certified In High Salt Fog And High Ammonia Environment.

5. Junction Box Certified According To IEC 62790, IP 67 Approved, 3 By Pass Diodes
6. Glass High Transmission, Low Iron, Tempered, ARC, Transparent, 2.0 MM

7. Mechanical Load Test: 5400Pa

8. Front Glass: 2.0mm, Anti-Reflection Coating

9. Frame: Anodized Aluminium Alloy

10. Junction Box: Ip68 Rated (3 By Pass Diodes)

11. Output Cables:4.0MM 350MM (+) / 300MM (-), Length Can Be Customized.

12. Connectors: MC4 Compatible



What is Shingled Cell Technology?

Conventional solar modules are made up of a number of solar cells electrically connected using metallic busbars. The solar cells on conventional solar modules have gaps around them and busbars typically cross over the cells to link them together. Shingled solar modules have layers of solar cells which touch each other and electrically connected using an electrically conductive adhesive (ECA). This eliminates the need for metallic busbars. This method means there are no gaps between the solar cells increasing the surface area of the silicon cells in the solar module. Plus there are no busbars covering the cells which reduce the light on the solar cells. This improves the electrical and mechanical performance and the aesthetics of the solar module.

Display

Why Choose Us？

Nuuko Power Co.,Ltd. is a professional solar photovoltaic product manufacturer specializing in the manufacturing and sales of solar panel systems since 2000.

We provide solar power generation system solutions with different solar panel installation structures, including ground-mounted solar systems, solar panel roof installations, photovoltaic carport structures, agricultural photovoltaic structures, etc. Support OEM and ODM services, welcome to visit the factory.

Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.
